| सामग्री: | इस्पात तार | जाल तार: | 5.0 मिमी |
|---|---|---|---|
| छेद: | 3" (76.2मिमी) x 3" (76.2मिमी) | सतह उपचार: | भारी गर्म डूबा हुआ जस्ती |
| जियोटेक्सटाइल: | 250-300 जीएसएम रेत का रंग, हरा रंग | जीवन अवधि: | 25 साल |
| आकार: | मिल 1 -मिल 10 | भू टेक्सटाइल रंग: | बेज-रेत का रंग |
| प्रमुखता देना: | Mil 7 Defensive Barriers,2.21m X2.13m X30.5m Military Defensive Barriers,Steel Wire Defensive Barriers |
||
Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty
1. Introduction :
Hesco barriers (also known as “Hesco bastions”) share the same basic design but differ substantially between military and civilian applications. The key distinctions lie in design intent, operating environment, functional emphasis, and specification choices:
Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty is gabion box. It is a combination of welded wire mesh frame outside and non-woven geotextile liner inside. Sand, soil, gravel and blinding are frequently used as filling because of geotextile liner.
Gabion bastions are mainly used in military and flood control for its modular structure and quick setup. For military, a gabion with 24 inches thickness can stop rifle bullets, shell fragments and other shrapnel. While for flood protection, gabion can be assembled soonest and come into use.
Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty have been used in many countries around the world including Afghanistan, Iraq, Bosnia, Kosovo, Yemen, Sri Lanka, Jordan, UAE and Turkey. Most military organizations currently use this products including the US Army, UK MOD, USMC, USAF and NATO.
A galvanized steel unit lined with geotextile fabric, Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty is completely assembled during manufacture, ensuring rapid installation. Available in a wide range of sizes, units can be joined and extended using the provided joining pins. The primary advantage of the product is its ability to utilise locally available fill material to rapidly construct walls and other structures with minimal manpower and resources.
2. Material:
It is made of galvanized welded mesh,spring with other fittings,can be filled with sand,earth,cement,stone,can be used in separate cell or some cells joint together.
3. Finish: electro galvanized,hot dipped galvanized,galfan coated,
4. Hesco barrier Specifications:
1) wire diameter: 4mm-5mm
2) hole: 3''x3''
3) size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested.
4) geotextile: in non-woven geotextile,color can be white,beige-sand color.
Hesco Defensive Barriers Specification
| Model | Height | Width | Length | Internal Cells |
| KN-1(Mil 1) | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
| KN-2(Mil 2) | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
| KN-3(Mil 3) | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
| KN-4(Mil 4) | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
| KN-5(Mil 5) | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| KN-6(Mil 6) | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| KN-7(Mil 7) | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
| KN-8(Mil 8) | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
| KN-9(Mil 9) | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
| KN-10(Mil 10) | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5=20 cells |
| KN-11(Mil 11) | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
| KN-12(Mil 12) | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
| KN-19(Mil 19) | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Defensive Barriers Use Deatils:
Unpack---Pull out and set up-----Connect together---- Fill and compact----Finished
Hesco Defensive Barriers Application :
♦ Perimeter security and defense walls
♦ Equipment revetments
♦ Personnel and material bunkers
♦ Observation points
♦ Defensive firing positions
♦ Guard posts
♦ Protection engineering of seaside area
♦ Border crossing checkpoints
♦ Protecting existing structures
♦ Flood control retaining wall
FAQ :
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000 USD, 100% in advance. Payment>=1000 USD, 30% T/T in advance ,balance before shippment.
